Chimney sweeper 350/30 mm
STEP SET DB-DC WEST EPDM
Other colors available on request
The Eurovent STEP SET DB-DC WEST EPDM is a chimney step in a complete assembly set consisting of the Eurovent® SUPPORT adapter and the Eurovent® STEP chimney step. The elements made of galvanized steel form a complete system for safe traffic on the roof slope with an angle of 15˚ to 60˚. The product features anti-slip corrugations on the whole surface and a hand grip. The set is available in several colour versions painted with powder paint according to RAL chart.
Advantages:
- Ready-to-install set
- Conforms to EN 516
- Double anti-corrosion protection
- Cement and ceramic roof tiles
Application and Technical Data
The Eurovent® STEP SET DB-DC WEST EPDM chimney step is used as a roof access element enabling safe and efficient movement of the chimney sweep in the chimney area. The set consists of two complete steps and includes all components required for the installation of two chimney steps. Thanks to a wide range of brackets, the product can be adapted to almost any type of roof covering. Installation is recommended on roof slopes with a pitch from 15° to 60°.
Fotos
System products
To ensure maximum safety and durability of the roof access system, STEP SET DB-DC WEST EPDM should be used in combination with:
- the Eurovent® VISTA DUO roof hatch, which provides convenient and safe access to the roof slope during maintenance works,
- Eurovent® roof clips, stabilising the roofing and increasing the resistance of step installation points to wind action and snow loads,
- Eurovent® highly vapour-permeable roof membranes, protecting the roof structure against moisture and supporting proper under-roof ventilation,
- Eurovent® sealing and adhesive tapes, which increase the tightness of installation joints, particularly around roof access elements.
The use of complete system solutions Eurovent® guarantees safety of use, fixing durability and full integration of roof access elements with the roof structure.
GOOD TO KNOW
When is STEP SET used instead of a walkway?
Steps create individual footholds along the access route; the walkway provides a larger standing area.
Is STEP SET complete?
Yes, it combines STEP with the appropriate SUPPORT bracket and installation components.
Why is the surface embossed?
To improve footwear grip.
How should LONG, SHORT or WEST EPDM be selected?
According to the exact tile model and compatibility data.
Can steps be positioned freely?
No. Their layout must follow the access route, roof structure and installation instructions.
