Fixing Profile

GEO LINE

Eurovent® GEO LINE

The Eurovent® GEO LINE profile is designed for finishing and fixing foundation membranes. Its shape has been designed so that the upper edge of the foundation membrane fits closely against the insulated surface. It is manufactured from a special plastic material, providing an estimated service life of more than 20 years.

Advantages:

  • quick and easy to install
  • designed to fit foundation membranes
  • corrosion-resistant

Application and Technical Data

The Eurovent® GEO LINE profile is used for fixing and finishing the upper edge of foundation membranes on insulated surfaces. Thanks to its precisely designed shape, a correctly installed profile ensures that the foundation membrane fits tightly against the surface.

Material
High-density polyethylene (HDPE)
Length
2.0 lm
Cardboard
25 pcs.
Package
25 pcs.
Pallet
10 000 pcs.

Documents

Technical Data Sheet
GEO LINE

Fotos

Eurovent® GEO LINE Eurovent® GEO LINE
Eurovent® GEO LINE zastosowanie Eurovent® GEO LINE zastosowanie

System products

For maximum effectiveness of damp-proofing and long-term protection of foundation structures, Eurovent® GEO LINE should be used in combination with:

  • Eurovent® filtration geotextiles, supporting substrate stabilisation and separation,
  • Eurovent® drainage mats and drainage accessories, improving the drainage of water from the ground,
  • Eurovent® sealing and adhesive tapes, ensuring tight connections at junctions with vertical and horizontal waterproofing,
  • Eurovent® foundation membranes and fixing accessories, enabling quick and durable installation of the system.

Using complete Eurovent® system solutions provides effective protection against moisture and long-term protection of foundations.

GEO LINE
GEO LINE
Fixing Profile
GEO 8
GEO 8
Foundation membrane
MAUER HDPE
MAUER HDPE
Damp-Proof Course
Eurovent® GEO LINE
GEO LINE
GEO 8
MAUER HDPE
FAQ

GOOD TO KNOW

What is the GEO LINE profile used for?

For finishing and fixing the top edge of a foundation membrane against a wall.

Why should the top edge of a dimpled membrane be protected?

An open edge can allow soil and other contaminants behind the membrane, which may impair the protective or drainage space.

Does GEO LINE seal the wall waterproofing?

No. The profile holds and finishes the foundation membrane but does not replace the required waterproofing seals.

What is GEO LINE made of?

High-density polyethylene, HDPE, so the profile does not corrode.

How should the profile fixings be selected?

According to the substrate and insulation build-up, in line with the installation requirements.
